Part numbers and dimensions of 2 tubes angle connector with nut cavities and invisible union
| Reference | For Tube |
Tube Thickness |
L |
Angle (A) |
Nut Spot (SW) / Metric (M) |
More Info. |
|||||||
|---|---|---|---|---|---|---|---|---|---|---|---|---|---|
| 02300400177 | 25 x 25 | 1,50 | 57,00 | 120º | SW 13 | ||||||||
| 02300400178 | 25 x 25 | 1,50 | 55,00 | 135º | SW 13 |
