Description and features
The THCLP articulated connector has been designed to connect 2 square tubes. The articulation range, as well as the type of rotation and locking, vary between each reference and can be consulted in the 'Angle' column.The Nylon (PA6) used is highly resistant and is characterized by a very long life and great resistance to aging. According to the reference, they have a fiberglass reinforcement which provides greater rigidity, dimensional and thermal stability.
* Type 1: Free rotation movement.
* Type 2: Rotation movement with 15º internal teeth.
* Type 3: Rotational movement with internal stop at 0º, 90º, 180º positions.
* Type 4: Rotational movement with a stop at 180º.
Please consult our sales office if the measurement or any other product specification is not within our standard program.
Product images and technical drawings
Product view
Technical drawing
Video
Part numbers and dimensions of 2 tubes hinge connector
| Reference | For Tube |
Tube Thickness |
L |
Angle (A) [Type] |
More Info. |
||||||||
|---|---|---|---|---|---|---|---|---|---|---|---|---|---|
| 02300400156 | 25 x 25 | 1,50 | 38,00 | 45º to 195º [2] | |||||||||
| 02300400157 | 25 x 25 | 1,50 | 38,00 | 45º to 195º [1] | |||||||||
| 02300400169 | 25 x 25 | 1,50 | 39,00 | 0º to 180º [4] | |||||||||
| 02300400170 | 25 x 25 | 1,50 | 39,00 | 0º to 190º [1] | |||||||||
| 02300400171 | 25 x 25 | 1,50 | 39,00 | 60º to 242º [1] | |||||||||
| 02300400803 | 30 x 30 | 1,50 | 41,00 | 45º to 200º [1] | |||||||||
| 02300400158 | 30 x 30 | 4,50 | 41,00 | 45º to 200º [1] | |||||||||
| 02300400800 | 35 x 35 | 2,00 | 41,00 | 45º to 200º [1] | |||||||||
| 02300400168 | 40 x 40 | 2,00 | 50,00 | 0º to 180º [3] |
