Description and features
Our AKAAK rigid levelling feet feature a round base with a minimalist design suitable for a wide range of applications. They are available in different base configurations to meet various installation requirements.
Three base types are available: type 1, without slot; type 2, with a screwdriver slot and rounded edges; and type 3, with a slot, one rounded edge and one straight edge. Depending on the base type, the material used may vary.
· Base material: Polypropylene (PP) and Low-density polyethylene (LDPE) depending on the base type
· Base diameters: 15 mm / 20 mm / 25 mm / 30 mm / 35 mm
· Colours: Black (RAL 9017) and Pearl Grey (RAL 7035)
· Thread: Zinc-plated steel M4 to M10
Stainless steel threads can be manufactured depending on the reference. Please contact our sales department.
RAL colors manufactured Product images and technical drawings
Product view
Technical drawing
Video
| 02500100255 | M4 | 10,00 | 20,00 | 8,00 | 3 | ||||||||
| 02500100256 | M4 | 10,00 | 25,00 | 8,00 | 3 | ||||||||
| 02500100245 | M5 | 17,00 | 15,10 | 6,00 | 1 | ||||||||
| 02500100246 | M5 | 22,50 | 15,10 | 6,00 | 1 | ||||||||
| 02500100247 | M5 | 27,50 | 15,10 | 6,00 | 1 | ||||||||
| 02500100248 | M5 | 38,00 | 15,10 | 6,00 | 1 | ||||||||
| 02500100249 | M5 | 48,00 | 15,10 | 6,00 | 1 | ||||||||
| 02500100257 | M6 | 10,00 | 20,00 | 8,00 | 2 | ||||||||
| 02500100259 | M6 | 10,00 | 25,00 | 8,00 | 2 | ||||||||
| 02500100261 | M6 | 10,00 | 30,00 | 8,00 | 2 | ||||||||
| 02500100250 | M6 | 17,00 | 15,10 | 6,00 | 1 | ||||||||
| 02500100258 | M6 | 20,00 | 20,00 | 8,00 | 2 | ||||||||
| 02500100260 | M6 | 20,00 | 25,00 | 8,00 | 2 | ||||||||
| 02500100262 | M6 | 20,00 | 30,00 | 8,00 | 2 | ||||||||
| 02500100251 | M6 | 22,50 | 15,10 | 6,00 | 1 | ||||||||
| 02500100252 | M6 | 27,50 | 15,10 | 6,00 | 1 | ||||||||
| 02500100253 | M6 | 37,00 | 15,10 | 6,00 | 1 | ||||||||
| 02500100254 | M6 | 47,00 | 15,10 | 6,00 | 1 | ||||||||
| 02500100275 | M8 | 10,00 | 35,00 | 11,50 | 2 | ||||||||
| 02500100263 | M8 | 11,00 | 20,00 | 8,00 | 3 | ||||||||
| 02500100266 | M8 | 11,00 | 25,00 | 8,00 | 3 | ||||||||
| 02500100268 | M8 | 11,00 | 30,00 | 8,00 | 3 | ||||||||
| 02500100270 | M8 | 15,00 | 30,00 | 11,50 | 2 | ||||||||
| 02500100276 | M8 | 15,00 | 35,00 | 11,50 | 2 | ||||||||
| 02500100264 | M8 | 20,00 | 20,00 | 8,00 | 3 | ||||||||
| 02500100267 | M8 | 20,00 | 25,00 | 8,00 | 3 | ||||||||
| 02500100269 | M8 | 20,00 | 30,00 | 8,00 | 3 | ||||||||
| 02500100271 | M8 | 20,00 | 30,00 | 11,50 | 2 | ||||||||
| 02500100277 | M8 | 20,00 | 35,00 | 11,50 | 2 | ||||||||
| 02500100272 | M8 | 25,00 | 30,00 | 11,50 | 2 | ||||||||
| 02500100265 | M8 | 30,00 | 20,00 | 8,00 | 3 | ||||||||
| 02500100273 | M8 | 30,00 | 30,00 | 11,50 | 2 | ||||||||
| 02500100274 | M8 | 40,00 | 30,00 | 11,50 | 2 | ||||||||
| 02500100278 | M10 | 15,00 | 30,00 | 11,50 | 2 | ||||||||
| 02500100283 | M10 | 20,00 | 35,00 | 11,50 | 2 | ||||||||
| 02500100279 | M10 | 25,00 | 30,00 | 11,50 | 2 | ||||||||
| 02500100280 | M10 | 30,00 | 30,00 | 11,50 | 2 | ||||||||
| 02500100284 | M10 | 30,00 | 35,00 | 11,50 | 2 | ||||||||
| 02500100281 | M10 | 35,00 | 30,00 | 11,50 | 2 | ||||||||
| 02500100282 | M10 | 41,00 | 30,00 | 12,00 | 2 |
