Description and features
Our ribbed insert for rectangular tubes has a metal nut inserted during the injection process. It is also available for square tubes: LJ, round tubes LJRL, and triangle tubes: LJZZ. It is suitable with our adjustable feet group.
  RAL colors manufactured Part numbers and dimensions of Rectangular threaded tube insert
| Reference | For Tube |
Tube Thickness |
Metric Thread |
h / L |
D x B |
H |
d x b |
d1 x b1 |
More Info. |
||||
|---|---|---|---|---|---|---|---|---|---|---|---|---|---|
| 00300400331 | 30 x 20 | 1,50 | M10 | 5,00 / 20,00 | 29,90 x 20,20 | 5,00 | 24,10 x 14,50 | 28,20 x 18,50 | |||||
| 00300400335 | 40 x 20 | 1,50 | M10 | 5,00 / 15,50 | 40,50 x 20,50 | 8,00 | 35,00 x 15,00 | 39,10 x 18,60 | |||||
| 00300400337 | 50 x 25 | 1,50 | M10 | 5,00 / 13,00 | 50,00 x 25,10 | 8,00 | 45,40 x 19,40 | 49,50 x 23,50 | |||||
| 00300400338 | 50 x 40 | 1,50 | M10 | 5,00 / 17,00 | 50,00 x 40,10 | 6,50 | 44,50 x 34,50 | 47,90 x 37,90 | |||||
| 00300400339 | 60 x 30 | 1,50 | M10 | 5,00 / 13,50 | 60,20 x 30,20 | 6,00 | 54,70 x 24,70 | 57,80 x 28,00 |
