Product images and technical drawings
Product view
Technical drawing
Video
Part numbers and dimensions of 3 tubes hinge connector
| Reference | For Tube |
Tube Thickness |
L |
H |
Angle (A) [Type] |
More Info. |
|||||||
|---|---|---|---|---|---|---|---|---|---|---|---|---|---|
| 02300400246 | 30,00 | 2,00 | 40,00 | 42,00 | 45º to 200º [1] | ||||||||
| 02300400247 | 30,00 | 3,00 | 40,00 | 42,00 | 45º to 200º [1] |
