Product images and technical drawings
Product view
Technical drawing
Video
Part numbers and dimensions of 2 tubes hinge connector
| Reference | For Tube |
Tube Thickness |
L |
Angle (A) |
More Info. |
||||||||
|---|---|---|---|---|---|---|---|---|---|---|---|---|---|
| 02300400244 | 30,00 | 2,00 | 40,00 | 45º to 200º [1] | |||||||||
| 02300400245 | 30,00 | 3,00 | 40,00 | 45º to 200º [1] | |||||||||
| 02300400267 | 40,00 | 2,00 | 44,00 | 40º to 190º [1] |
If you are interested in our family SROBL, you may be interested in these families as well:
