Description and features
Our elbow connector has been designed in order to connect 2 square tubes. It is supplied with the internal core in steel, or in zinc coated steel. It has a thread of M8 or M10, depending on the reference.Product images and technical drawings
Product view
Technical drawing
Video
Part numbers and dimensions of 2 tubes elbow connector with metal core, thread and visible union
| Reference | For Tube |
Tube Thickness |
L |
H |
Metric (M) |
More Info. |
|||||||
|---|---|---|---|---|---|---|---|---|---|---|---|---|---|
| 02300400140 | 25 x 25 | 1,50 | 48,50 | 25,00 | M10 | ||||||||
| 02300400141 | 25 x 25 | 1,50 | 52,00 | 25,00 | M8 | ||||||||
| 02300400142 | 30 x 30 | 2,00 | 47,00 | 30,00 | M10 | ||||||||
| 02300400143 | 30 x 30 | 2,00 | 47,00 | 30,00 | M8 |
