Our adjustable foot has a decorative round felted base. It is also available without felt, please visit LKF.

Material:  LDPE   ZCS   FELT
Standard colors: Black / RAL colors manufactured
Drawing PDF:
UL94:
IP:
RoHS:
Measures expressed in: Millimeters


Reference
Metric Thread (M)
L
H
D
Usable Thread
d
h
Felt

PDF
3D IGS
Add
00301200406 M8 20,00 8,00 34,00 16,00 27,50 2,30
00301200407 M8 30,00 8,00 34,00 26,00 27,50 2,30
00301200408 M8 40,00 8,00 34,00 36,00 27,50 2,30
00301200409 M8 50,00 8,00 34,00 46,00 27,50 2,30
00301200410 M10 20,00 8,00 34,00 16,00 27,50 2,30
00301200411 M10 30,00 8,00 34,00 24,00 27,50 2,30
00301200412 M10 40,00 8,00 34,00 36,00 27,50 2,30
00301200413 M10 50,00 8,00 34,00 45,00 27,50 2,30
