Product images and technical drawings
Product view
Technical drawing
Video
Part numbers and dimensions of 2 tubes hinge connector with nut cavities and reinforcement
| Reference | For Tube |
Tube Thickness |
L |
Angle (A) [Tipo] |
Nut Spot (SW) / Metric (M) |
More Info. |
|||||||
|---|---|---|---|---|---|---|---|---|---|---|---|---|---|
| 02300400176 | 25 x 25 | 1,50 | 54,50 | 60º to 300º [1] | SW 13 |
If you are interested in our family THCLS, you may be interested in these families as well:
