Our nylon 100º flat head (countersunk head) screws provide excellent resistance against chemicals (see table of properties). It is a material with a high level of dielectric strength, it does not rust and prevents damage due to breaking strength during mechanical stress.

Drawing PDF:
UL94:   V2
IP:
RoHS:
Measures expressed in: Millimeters


Reference
Thread
L
D
H
J
T
Type



More
Info.
00100401990 2 · 56 3,18 4,00 0,94 0,69 0,39 UNC
00100401991 2 · 56 4,76 4,00 0,94 0,69 0,39 UNC
00100401992 2 · 56 7,94 4,00 0,94 0,69 0,39 UNC
00100401993 2 · 56 12,70 4,00 0,94 0,69 0,39 UNC
00100401994 2 · 56 15,88 4,00 0,94 0,69 0,39 UNC
00100401995 4 · 40 4,76 5,28 1,24 0,89 0,52 UNC
00100401996 4 · 40 6,35 5,28 1,24 0,89 0,52 UNC
00100401997 4 · 40 7,94 5,28 1,24 0,89 0,52 UNC
00100401998 4 · 40 9,53 5,28 1,24 0,89 0,52 UNC
00100401999 4 · 40 12,70 5,28 1,24 0,89 0,52 UNC
00100402000 4 · 40 13,49 5,28 1,24 0,89 0,52 UNC
00100402001 4 · 40 15,88 5,28 1,24 0,89 0,52 UNC
00100402002 4 · 40 25,40 5,28 1,24 0,89 0,52 UNC
00100402003 6 · 32 4,76 6,57 1,52 1,10 0,66 UNC
00100402004 6 · 32 9,53 6,57 1,52 1,10 0,66 UNC
00100402005 6 · 32 12,70 6,57 1,52 1,10 0,66 UNC
00100402006 6 · 32 15,88 6,57 1,52 1,10 0,66 UNC
00100402007 6 · 32 25,40 6,57 1,52 1,10 0,66 UNC
00100402008 6 · 32 28,58 6,57 1,52 1,10 0,66 UNC
00100402009 6 · 32 38,10 6,57 1,52 1,10 0,66 UNC
00100402010 8 · 32 9,53 7,84 1,83 1,26 0,80 UNC
00100402011 8 · 32 13,49 7,84 1,83 1,26 0,80 UNC
00100402012 8 · 32 25,40 7,84 1,83 1,26 0,80 UNC
00100402013 10 · 24 20,64 9,12 2,11 1,40 0,93 UNC
00100402014 10 · 32 6,35 9,12 2,11 1,40 0,93 UNF
00100402015 10 · 32 12,70 9,12 2,11 1,40 0,93 UNF
00100402016 10 · 32 17,46 9,12 2,11 1,40 0,93 UNF
00100402017 1/4 · 20 9,53 12,05 2,79 1,77 1,23 UNC
00100402018 1/4 · 20 19,05 12,05 2,79 1,77 1,23 UNC
00100402019 1/4 · 20 22,23 12,05 2,79 1,77 1,23 UNC
00100402020 1/4 · 20 25,40 12,05 2,79 1,77 1,23 UNC
00100402021 1/4 · 20 26,99 12,05 2,79 1,77 1,23 UNC
00100402022 1/4 · 20 28,58 12,05 2,79 1,77 1,23 UNC
00100800200 6 · 32 6,35 6,57 1,52 1,10 0,66 UNC
00100800200 6 · 32 6,35 6,57 1,52 1,10 0,66 UNC

If you are interested in our family MWQ, you may be interested in these families as well:

This conical finishing washer has been designed for containing countersunk flat head screws. Our finishing washer protects furniture from scratching, covers misaligned holes, etc… This part may also be used as glide bumper, feet, and spacer. Please visit our families: Bumpers & Feet, and our family: Screws & Nuts.   Our nylon hexagonal nuts (DIN 934 nuts) provide excellent resistance against chemicals (see table of properties). It is a material with a high level of dielectric strength, it does not rust and prevents damage due to breaking strength during mechanical stress.   Our nylon wing nuts (DIN 3518 nuts) provide excellent resistance against chemicals (see table of properties). It is a material with a high level of dielectric strength, it does not rust and prevents damage due to breaking strength during mechanical stress.   Our nylon 82º flat head (countersunk head) screws provide excellent resistance against chemicals (see table of properties). It is a material with a high level of dielectric strength, it does not rust and prevents damage due to breaking strength during mechanical stress. Our flat head screws in polycarbonate are transparent.   Our nylon oval slotted head screws (raised countersunk slotted head screws) (DIN 964 screws) provide excellent resistance against chemicals (see table of properties). It is a material with a high level of dielectric strength, it does not rust and prevents damage due to breaking strength during mechanical stress.
