The TUAB washers (according to DIN 34815 (DIN 125), DIN 34816 (DIN 9021) and DIN 433) are manufactured in different engineered materials that favor properties such as chemical, mechanical, oxidation resistance, etc. They are available in PP -Polypropylene-, POM -Acetal Resin-, PVDF -Polyvinylidene Fluoride-, PEEK -Polietereterketone- and PAGF -Nylon with the possibility of up to 50% fiberglass-.
Contact us for further information and to check the availability of the references of your interest in the indicated materials.

Drawing PDF:
UL94:
IP:
RoHS:
Measures expressed in: Millimeters


 Filter by measurements
B Margen +/-
A Margen +/-
T Margen +/-



Reference
B
A
T
Metric
DIN



More
Info.
03800200801 4,30 9,00 0,80 M4 DIN125
03800200805 5,30 10,00 1,00 M5 DIN125
03800200823 5,30 15,00 1,50 M5 DIN9021
03800200806 6,40 12,00 1,60 M6 DIN125
03800200830 6,40 14,00 1,60 M6
03800200824 6,40 19,00 1,50 M6 DIN9021
03800200808 8,40 17,00 1,60 M8 DIN125
03800200831 8,40 21,00 2,00 M8
03800200825 8,40 25,00 2,00 M8 DIN9021
03800200809 10,50 21,00 2,00 M10 DIN125
03800200832 10,50 24,00 2,00 M10
03800200826 10,50 30,00 2,50 M10 DIN9021
03800200810 13,00 24,00 2,50 M12 DIN125
03800200833 13,00 28,00 2,50 M12
03800200827 13,00 40,00 3,00 M12 DIN9021
03800200811 15,00 30,00 3,00 M14 DIN125
03800200812 17,00 30,00 3,00 M16 DIN125
03800200834 17,00 32,00 3,00 M16
03800200828 17,00 50,00 3,00 M16 DIN9021
03800200813 19,00 34,00 3,00 M18 DIN125
03800200814 21,00 37,00 3,00 M20 DIN125
03800200835 21,00 39,00 3,00 M20
03800200829 22,00 60,00 4,00 M20 DIN9021
03800200815 23,00 39,00 3,00 M22 DIN125
03800200816 25,00 44,00 4,00 M24 DIN125
03800200836 25,00 50,00 4,00 M24
03800200817 28,00 50,00 4,00 M27 DIN125
03800200837 28,00 56,00 4,00 M27
03800200818 31,00 56,00 4,00 M30 DIN125
03800200838 31,00 60,00 4,00 M30
03800200819 34,00 60,00 5,00 M33 DIN125
03800200839 34,00 66,00 5,00 M33
03800200840 37,00 72,00 5,00 M36
03800200841 39,00 77,00 6,00 M39

If you are interested in our family TUAB, you may be interested in these families as well:

The MDIN hexagonal nuts (conformable with DIN 34814 - former DIN 934/555) are manufactured in different <b>engineered materials</b> that favor properties such as <i>chemical, mechanical, oxidation resistance, etc.</i> They are available in <b>PP</b> -Polypropylene-, <b>POM</b> -Acetal Resin-, <b>PVDF</b> -Polyvinylidene Fluoride-, <b>PEEK</b> -Polietereterketone- and <b>PAGF</b> -<i>Nylon with the possibility of up to 50% fiberglass-</i>.
<br>
Contact us for further information and to check the availability of the references of your interest in the indicated materials.   The ALLA hexagonal screw nuts (conformable with DIN 34810 - former DIN 933) are manufactured in different <b>engineered materials</b> that favor properties such as <i>chemical, mechanical, oxidation resistance, etc.</i> They are available in <b>PP</b> -Polypropylene-, <b>POM</b> -Acetal Resin-, <b>PVDF</b> -Polyvinylidene Fluoride-, <b>PEEK</b> -Polietereterketone- and <b>PAGF</b> -<i>Nylon with the possibility of up to 50% fiberglass-</i>.
