Description and features
This two-piece rivet is designed for flexible plastic I.D. or security bracelet. Male and female rivets snap into pre-punched holes in the plastic bracelet and then snap together. It is very difficult to remove without damaging, preventing its loss or its modification. Male and female parts are packed and sold separately.
Possible to get dyed colors Product images and technical drawings
Product view
Technical drawing
Video
Part numbers and dimensions of Female-Male rivet
| Reference | Hole size |
Panel thickness |
A |
B |
L |
Piece male or female |
More Info. |
||||||
|---|---|---|---|---|---|---|---|---|---|---|---|---|---|
| 00100300500 | · | · | 9,65 | 1,92 | 2,14 | FEMALE | |||||||
| 00100300501 | 5,40 | 3,20 to 5,50 | 9,65 | 5,84 | 1,58 | Male |
If you are interested in our family MRB, you may be interested in these families as well:
