Description and features
Our corrugated polypropylene tube MPP is a flexible flame-resistant component designed for technical applications in industrial and outdoor environments. It offers excellent UV resistance and a service life of at least 20 years.
Material: Thermally stabilized polypropylene.
Operating temperature: -40 °C / +130 °C (peaks up to +150 °C).
Flammability: Flame-retardant and self-extinguishing UL94-V2, FMVSS 302, DIN 75200.
Features: High flexibility, resistance to alcohols, grease, mineral oils and fuels. Suitable for photovoltaic systems, mechanical and automotive industries. Tensile strength 26 MPa, elastic modulus 1300 MPa, elongation at break >250%.
Supply & packaging: Unit of measure 1 meter, bulk supply without cuts, coils of 10, 25, 50 or 100 meters depending on reference, special lengths on request.
Each reference is available in standard version or with longitudinal opening along the tube.
Product images and technical drawings
Product view
Technical drawing
Video
| 02010001000 | 4,50 | 7,10 | 4,50 | 12,00 | |||||||||
| 02010001001 | 7,50 | 9,90 | 6,90 | 15,00 | |||||||||
| 02010001002 | 8,50 | 11,40 | 8,50 | 18,00 | |||||||||
| 02010001003 | 10,00 | 12,90 | 10,10 | 18,00 | |||||||||
| 02010001004 | 12,00 | 15,60 | 12,50 | 20,00 | |||||||||
| 02010001005 | 13,00 | 15,80 | 12,90 | 22,00 | |||||||||
| 02010001006 | 14,00 | 18,30 | 14,50 | 25,00 | |||||||||
| 02010001007 | 17,00 | 21,00 | 16,80 | 30,00 | |||||||||
| 02010001008 | 19,00 | 24,00 | 19,40 | 35,00 | |||||||||
| 02010001009 | 22,00 | 25,20 | 21,80 | 37,00 | |||||||||
| 02010001010 | 23,00 | 28,40 | 23,70 | 42,00 | |||||||||
| 02010001011 | 26,00 | 31,00 | 26,40 | 47,00 | |||||||||
| 02010001012 | 29,00 | 34,10 | 29,30 | 60,00 | |||||||||
| 02010001013 | 37,00 | 41,60 | 36,50 | 70,00 | |||||||||
| 02010001014 | 50,00 | 53,60 | 47,80 | 100,00 | |||||||||
| 02010001015 | 56,00 | 67,90 | 56,30 | 100,00 | |||||||||
| 02010001016 | 70,00 | 79,20 | 66,50 | 135,00 | |||||||||
| 02010001017 | 95,00 | 106,00 | 91,00 | 150,00 |
