Product images and technical drawings
Product view
Technical drawing
Video
Part numbers and dimensions of 6 tubes B connector
| Reference | For Tube |
Tube Thickness |
L |
H |
More Info. |
||||||||
|---|---|---|---|---|---|---|---|---|---|---|---|---|---|
| 02300400236 | 13,50 x 13,50 | 1,25 | 20,00 | 13,00 | |||||||||
| 02300900180 | 25 x 25 | 2,00 | 32,00 | 25,00 | |||||||||
| 02300900181 | 25 x 25 | 2,00 | 40,00 | 25,00 | |||||||||
| 02300900166 | 30 x 30 | 1,50 | 50,00 | 30,00 |
