Description and features
Our 5-way connector has been designed for square tubes. It is supplied with an internal core in steel or in zinc coated steel. It has a thread of M8 or M10, depending on the reference.Product images and technical drawings
Product view
Technical drawing
Video
Part numbers and dimensions of 5 tubes A connector with metal core and thread
| Reference | For Tube |
Tube Thickness |
L |
H |
Metric (M) |
More Info. |
|||||||
|---|---|---|---|---|---|---|---|---|---|---|---|---|---|
| 02300400232 | 25 x 25 | 1,50 | 54,00 | 25,00 | M8 | ||||||||
| 02300400233 | 25 x 25 | 1,50 | 54,00 | 25,00 | M10 | ||||||||
| 02300400234 | 30 x 30 | 2,00 | 47,00 | 30,00 | M8 | ||||||||
| 02300400235 | 30 x 30 | 2,00 | 47,00 | 30,00 | M10 |
