Product images and technical drawings
Product view
Technical drawing
Video
Part numbers and dimensions of 4 tubes hinge connector
| Reference | For Tube |
Tube Thickness |
L / H |
Angle (A) [Type] |
More Info. |
||||||||
|---|---|---|---|---|---|---|---|---|---|---|---|---|---|
| 02300400218 | 25 x 25 | 1,50 | 38,00 / 42,00 | 0º to 190º [1] | |||||||||
| 02300400219 | 25 x 25 | 1,50 | 38,00 / 42,00 | 0º to 180º [4] | |||||||||
| 02300400228 | 40 x 40 | 2,00 | 49,00 / 42,50 | 0º to 180º [3] |
