Description and features
Our C connector has been designed to connect 4 square tubes. It has a thread of M8 or M10, depending on the reference. More possibilities of sizes available under minimum order, consult us.Product images and technical drawings
Product view
Technical drawing
Video
Part numbers and dimensions of 4 tubes C connector with metal core and thread
| Reference | For Tube |
Tube Thickness |
L |
H |
Metric (M) |
More Info. |
|||||||
|---|---|---|---|---|---|---|---|---|---|---|---|---|---|
| 02300400224 | 25 x 25 | 1,50 | 52,00 | 25,00 | M8 | ||||||||
| 02300400225 | 25 x 25 | 1,50 | 52,00 | 25,00 | M10 | ||||||||
| 02300400290 | 30 x 30 | 2,00 | 47,00 | 30,00 | M10 |
