Part numbers and dimensions of 3 tubes T connector with metal core and thread
| Reference | For Tube |
Tube Thickness |
L |
H |
Metric (M) |
More Info. |
|||||||
|---|---|---|---|---|---|---|---|---|---|---|---|---|---|
| 02300400206 | 25 x 25 | 1,50 | 51,00 | 25,00 | M8 | ||||||||
| 02300400207 | 25 x 25 | 1,50 | 51,00 | 25,00 | M10 | ||||||||
| 02300400208 | 30 x 30 | 2,00 | 47,00 | 30,00 | M8 | ||||||||
| 02300400209 | 30 x 30 | 2,00 | 47,00 | 30,00 | M10 |
