Product images and technical drawings
Product view
Technical drawing
Video
Part numbers and dimensions of 2 tubes straight connector with a cavity for metal core and visible union
| Reference | For Tube |
Tube Thickness |
L |
H |
More Info. |
||||||||
|---|---|---|---|---|---|---|---|---|---|---|---|---|---|
| 02300400240 | 40 x 20 | 1,50 | 37,00 | 5,00 | |||||||||
| 02300400261 | 40 x 20 | 2,00 | 35,00 | 5,00 |
