Our connector for rectangular tubes has been designed with 2 cavities for hexagonal nuts. We can supply the part without nuts, or with a nut up, or one nut down, or with the 2 nuts. Please consult us.
 Download technical information

Drawing PDF:
UL94:
IP:
RoHS:
Measures expressed in: Millimeters
Video:

LJEZ
LJEZ

Reference
For Tube
Tube Thickness
L
E / H
Nut Spot (SW) / Metric (M)



More
Info.
02300400013 30 x 15 1,50 42,00 32,00 / 12,00 SW 10
02300400010 30 x 15 1,50 43,00 31,80 / 11,80 SW 8
02300400014 30 x 20 1,50 41,00 32,00 / 12,00 SW10
00300401065 30 x 20 1,50 41,50 30,00 / 10,00 SW 13
02300400011 30 x 20 2,00 46,00 32,00 / 12,00 SW 10
02300400004 35 x 25 1,50 41,00 30,00 / 10,00 SW 17
02300400012 40 x 15 2,00 42,00 33,00 / 14,00 SW 8
00300401067 40 x 20 1,50 42,00 30,00 / 10,00 SW 13
00300401068 40 x 25 2,00 42,00 30,00 / 10,00 SW 17
02300400005 50 x 25 1,20 to 1,60 42,00 30,00 / 10,00 SW 17
02300400006 50 x 25 2,00 37,00 25,00 / 8,50 SW 17
00300401069 50 x 30 2,00 42,50 30,00/ 10,10 SW 17
02300400008 60 x 20 2,00 42,00 30,00 / 12,00 SW 13
00300401070 60 x 30 2,00 40,00 30,00 / 10,00 SW 17
02300400009 60 x 40 2,00 39,00 26,00 / 9,00 SW 17

If you are interested in our family LJEZ, you may be interested in these families as well:

Our straight connector has been designed for rectangular tubes. It is supplied with or without internal metal core.   LF end caps are designed to ensure <b>secure fastening</b>, <b>easy assembly</b>, and a <b>high-quality finish</b> thanks to the rounded shape of their head. They are used to seal tubes and/or various openings that must withstand mechanical stress and are <b><i>recommended as end caps for chairs and/or furniture</b></i>. <br> For use as sliding stoppers and to facilitate easy assembly in tubes with thicker walls, we recommend chamfering the tube's inner diameter (approx. 0.3 - 0.5 x 60°). <br> <b>Special colors</b>, <b>company logos</b>, and production using <b>TPE material</b> (non-slip, sound-reducing, and resistant to a wider temperature range) are available upon request—please contact us. <br> Due to technical production reasons, a residual gate may exceed the L dimension. Depending on the selected item, the surface finish may vary between polished and textured. <br>
