Product images and technical drawings
Product view
Technical drawing
Video
Part numbers and dimensions of 2 tubes elbow connector with metal core, thread and visible union
| Reference | For Tube |
Tube Thickness |
L |
H |
Metric (M) |
More Info. |
|||||||
|---|---|---|---|---|---|---|---|---|---|---|---|---|---|
| 02300400159 | 25 x 25 | 1,50 | 52,00 | 25,00 | M8 |
